• ARM^® Cortex™-A7 @1.2GHz

• Supports H.264 encoder up to 720p@60fps
• Supports H.264 and JPEG/MJPEG decoder up to 1080p@30fps

• Integrated ISP up to 5M pixels
• Supports two channel outputs for display and encoding respectively
• Supports various input and output formats
• Supports AE/AF/AWB
• Supports saturation adjustment/noise reduction/defect pixel correction/ distortion correction

• SIP 16-bit DDR2

• Supports 8/10/12-bit parallel CSI and 2-lane MIPI CSI2
• Supports BT1120 input
• Supports capture resolution up to 5M with parallel interface
• Video capture resolution up to 1080p@30fps
• Supports RGB LCD output, up to 1024x768@60fps
• Supports Allwinner's next-gen SmartColor display technology for better visual effects for images & videos

• Supports two ADC channel and two DAC channels
• Supports one stereo headphone output
• Supports one differential microphone input

• Supports AES/DES/TDES, SHA1 and MD5

• SDIO, LRADC, SPI, TWI, UART, PWM, USB

• Supports Linux OS

• eLQFP 128（including one built-in DDR2）
