• DDR2/DDR3/DDR3L controller

• NAND Flash controller with 64-bit ECC

• ARM Mali400MP2

• Complies with OpenGL ES 2.0/1.1

• Integrated parallel 8-bit I/F YUV sensor I

• Integrated 24-bit parallel YUV 444 I/F

• Supports 5M CMOS sensor

•  Supports dual sensors

• HD H.264 2160p video decoding

• Multi-format FHD video decoding, including Mpeg1/2, Mpeg4 SP/ASP GMC, H.263, H.264, VP6/8, AVS jizun, Jpeg/Mjpeg, etc.

• H.264 High Profile 1080p@30fps or 720p@60fps encoding

• 3840x1080@30fps 3D decoding, BD/SBS/TAB/FP supported

• Complies with RTSP, HTTP,HLS,RTMP,MMS streaming media protocols

• Supports multi-channel HD display

• CPU/RGB/LVDS LCD interface

• Supports CVBS/YPbPr/VGA

•  Integrated TV decoder

• Integreted Hi-Fi 100db Audio codec

• Dual analog mic amplifiers
