CPU
• Octa-Core Cortex™-A7
• Low-power CoolFlexTM power management architecture
GPU• PowerVR SGX544 GPU
• Supports OpenGL ES 2.0/1.1, OpenCL 1.1, DX 9_3
Memory• Supports 32-bit DDR3/DDR3L/LPDDR3/LPDDR2
• Supports SLC/MLC/TLC/EF NAND with 64-bit ECC
• Supports eMMC
PIMC• AXP813
|
Camera• Integrated 5MP parallel CMOS sensor
• Integrated 8MP MIPI CSI controller
• Integrated 8MP ISP
Display• Supports TTL up to 1920x1200@60fps
• Supports LVDS up to 1366x768@60fps
• Supports MIPI DSI up to 1920x1200@60fps
Package• FCBGA 345
• 14mm x 14mm size
|
Connectivity• USB Host, USB Dual-Role (host/device)
• Ethernet MAC
• 2x SPI, 4x TWI, 6x UART, RSB
• 3x SD/MMC
• HSIC
• 2x I2S/PCM
• CIR, LRADC
Video• Supports multi-format 1080P@60fps video decoding
|
