A40i

工控行业平台级处理器

产品

芯片框图

A40i

基本规格

CPU Architecture

• Quad-core ARM Cortex-A7 MPCore Processor

• ARMv7 ISA standard ARM instruction set
• Thumb-2 Technology
• Jazeller RCT
• NEON Advanced SIMD
• VFPv4 floating point
• Hardware virtualization support
• Large Physical Address Extensions(LPAE)
• JTAG debug
• One general timer for per CPU
• 32KB Instruction and 32KB Data L1 cache for per CPU
• 256KB L2 cache

GPU Architecture

• 3D
‒ Mali400 MP2 GPU
‒ Support OpenGL ES 2.0 / OpenVG 1.1 standard
• 2D
‒ Support BLT and ROP2/3/4
‒ Support 90° /180° /270° rotation
‒ Support mirror/ alpha (plane and pixel alpha)/color key
‒ Format conversion: ARGB 8888/4444/1555,RGB565, MONO 1/2/4/8bpp, Palette 1/2/4/8bpp (input only), YUV

Memory Subsystem SDRAM

• Compatible with JEDEC standard DDR2/DDR3/DDR3L/LPDDR2/LPDDR3 SDRAM
• Up to 2GB address space
• 16 address signal lines and 3 bank signal lines
• 32-bit bus width

NAND Flash

• Supports SLC/MLC NAND and EF-NAND
• Supports SDR/Toggle DDR/ONFI DDR NAND interface
• 16 address signal lines and 3 bank signal lines
• up to 8-bit data bus width

SD/MMC Interface

• Up to four SMHC controllers
• Comply with eMMC standard specification V5.0
• Comply with SDIO card specification V3.0
• 1/4/8-bits bus width

USB

• One USB 2.0 OTG
• Two EHCI/OHCI compliant Hosts

Video Decoding

• Support picture size up to 3840x2160
• Support decoding speed up to 1080p@60fps
• Supported multi-formats: MPEG1/2, MPEG4 SP/ASP, WMV, H.263 including Sorenson Spark,H.264 BP/MP/HP, VP6/8, AVS/AVS+, JPEG/MJPEG, etc

Video Encoding

• H.264 HP up to 1080p@45fps
• JPEG baseline: picture size up to 4096x4096
• Alpha blending
• Thumb generation
• 4x2 scaling ratio from 1/16 to 64 arbitrary non-integer ratio

Video Output

• HDMI 1.4 transmitter with HDCP up to 1080p@60fps
• Supports 4 lanes MIPI DSI up to 1080p@60fps
• Supports LVDS interface up to 1920 x 1080@60fps
• Supports RGB interface up to 1920 x 1080@60fps
• Supports CVBS out, 4-ch CVBS, 1-ch YPbPr or 1-ch VGA

Analog Audio Output

• Stereo audio DAC
• Stereo capless headphone drivers
• One low-noise analog microphone bias
• Dedicated headphone outputs
• Two mixers to meet different requirements

Video Input

• Supports 4-ch analog CVBS in
• Supports Dual parallel interfaces:CSI0 and CSI1
• Supports CCIR656 protocol for each CSI
• Supports 16-bit BT1120 interface for CSI0
• Supports 24-bit RGB/YUV444 input for CSI1

Analog Audio Input

• Support four analog audio inputs
• Stereo audio ADC

EMAC

• Support 10/100Mbps MII PHY interface
• Comply with the IEEE 802.3-2002 standard

GMAC

• Support 10/100/1000Mbps RGMII/MII PHY interface
• Comply with the IEEE 802.3-2002 standard

Digital Audio

• One I2S compliant audio interface,supporting 8-channel and 2-channel input
• One PCM, supporting linear sample (8-bit or 16-bit), 8-bit u-law and A-law companded sample
• One AC97 audio codec, supporting 2-channel and 6-channel audio data output

PWM

• 8 PWM channels outputs
• Support cycle mode and pulse mode
• The pre-scale is from 1 to 64

Smart Card Reader

• One smart card reader controller supporting ISO/IEC 7816-3 and EMV2000 specifications
• Support synchronous and any other non-ISO 7816 and non-EMV cards

DMA

• 16 channels:8 channels with normal DMA,8 channels with dedicated DMA
• Support data width of 8/16/32 bits
• Support linear and IO address modes
• Support data transfer types with memory-to-memory, memory-to-peripheral,peripheral-to-memory

CIR

• A flexible receiver for IR remote
• Up to two IR controllers
• Programmable FIFO thresholds

UART

• Up to 8 UART controllers
• 64-Bytes Transmit and receive data FIFOs for all UART
• Compliant with industry-standard 16550 UARTs
• Support Infrared Data Association(IrDA) 1.0 SIRR

SATA

• One SATA Host controller
• Support SATA 1.5Gb/s and SATA 3.0Gb/s
• Comply with SATA spec 2.6
• Support external SATA(eSATA)

Keypad

• One keypad matrix interface up to 8 rows and 8 colums
• Interrupt for key press or key release
• Internal debouncing filter to prevent switching noises

TWI

• Up to 5 TWIs(Two Wire Interface) controllers
• Support Standard mode (up to 100K bps) and Fast mode (up to 400K bps)

SPI

• Up to 4 SPI controllers

Package

• BGA 468 balls,0.65mm ball pitch, 0.35mm ball size, 16x16mm

Operating Temperature

• - 40℃~ 85℃

方案亮点

工控平台级芯片,支持Android&Linux双系统,十年以上供货周期
工控平台级芯片,支持Android&Linux双系统,十年以上供货周期
工业品质标准,100ppm,工作温度-40-85℃
工业品质标准,100ppm,工作温度-40-85℃
支持双屏异显和多种显示接口 RGB/MIPI      /双LVDS/HDMI
支持双屏异显和多种显示接口 RGB/MIPI /双LVDS/HDMI
支持多路摄像头输入,DVP in*2/CVBS in*4
支持多路摄像头输入,DVP in*2/CVBS in*4
接口丰富 USB*3/GMAC/EMAC           /SATA/UART*8, etc.
接口丰富 USB*3/GMAC/EMAC /SATA/UART*8, etc.
...

典型机型
